Lightweight Gangways &
Marine Planks
Provide a safe transition from boat to dock or shore.
Our durable design ensures a long service life even on the busiest marinas, yacht clubs, or private residences. Unlike traditional heavy steel construction, our gangways and planks are made from sturdy but lightweight aluminum — no heavy equipment is needed. Your Alumidock gangway can easily be installed by two people or quickly removed for storms or seasonal storage.
The Alumidock Difference
Why we’re the standout USA-Made quality choice among gangway providers.
Specifications
Lightweight, corrosion-resistant aluminum
Side rails feature a rigid box girder design, and the top truss increases stability load capacity
Decking planks are fastened securely to the tubular cross members
Standard cleats provide additional foot grip
Advantages
✔︎ Replaces unsafe wooden ramps or rusty steel units
✔︎ 2,000 lb (907.18 kg) distributed load rating
✔︎ Sturdy enough to withstand high winds
✔︎ Easily removed for storms or off-season storage
✔︎ Safe transport of people & goods from boat to shore
How to configure your gangway
We build the gangway or plank you want precisely to your specifications.
Simply tell us the dimensions you need, and we’ll take it from there. All gangways come standard with a mounting bracket on the shore end, rubber-topped aluminum wheels at the float end, and handrail on both sides. Swivel casters or underneath rollers are available.
-
Considerations:
The estimated amount of traffic on your gangway
Options:
32 in (813 mm), 36 in (914 mm), 42 in (1067 mm)* or 48 in (1219 mm)
-
Considerations:
How far out will you need it to go?
Options:
Standard sizes range from 6 ft (1.83 m) and 40 ft (12.19 m)*
-
Wheels, rollers, swivel wheels or mounting brackets depending on the vertical or lateral movement requirement
*Custom lengths and widths can be made to order
Gangways & Marine Plank Pricing
-
12 - 20 ft (3.35 - 6.1 m): $1,805 - $3,792
22 - 30 ft (6.4 - 9.14 m): $3,040 - $4,451
32 - 40 ft (9.45 - 12.19 m): $4,682 - $5,671
-
12 - 20 ft (3.35 - 6.1 m): $2,092 - $3,049
22 - 30 ft (6.4 - 9.14 m): $3,333 - $4,826
32 - 40 ft (9.45 - 12.19 m): $5,067 - $6,099
-
12 - 20 ft (3.35 - 6.1 m): $2,368 - $3,705
22 - 30 ft (6.4 - 9.14 m): $3,935 - $5,507
32 - 40 ft (9.45 - 12.19 m): $5,759 - $6,973
-
12 - 20 ft (3.35 - 6.1 m): $2,855 - $4,371
22 - 30 ft (6.4 - 9.14 m): $4,559 - $6,409
32 - 40 ft (9.45 - 12.19 m): $6,503 - $8,133
Not sure which options to choose? No problem.
A member of our team will be happy to assist.
Product resources, guides & drawings
Keep your gangway in optimal condition
As a long-term leader in the industry, you can rely on Alumidock to support your installation, troubleshooting, and replacement parts needs into the future. Our complete line of replacement parts can be purchased online.
